Edwards Active Pirani Gauge Manual
. Wide range, regulated, internal power supply - Runs from standard dc power supplies +20 to +36 V.
Edwards APG100 series Active Pirani vacuum gauges are available in 2 models. The APG100-XM is the standard model and measures to 10-3 mbar, the APG100-XLC is a corrosion resistant version with measurement to 10-4 mbar. Both gauges feature compact size for easy installation, a linear output and a replaceable sensor tube. Edwards APG100 Active Pirani Vacuum Gauges are available in either standard or corrosion resistant versions offering measurement from atmosphere to 10 -3 or 10 -4 respectively. They are compatible with all Edwards TIC Instrument controllers and are fully RoHS compliant. The Edwards Active Pirani Gauges (APG). These gauges have a measuring range from atmosphere to 1 x 10-4 mbar and combine the gauge head and controller in one compact active unit. The well proven, cost effective and reliable Pirani range has a substantial user base with a successful track record in the measurement of rough and backing pressures across a broad spectrum of applications.
Tolerant to voltage fluctuations. Drive electronics combined in the gauge head - Reduces the system cost. Saves valuable rack space.
Medium and low pressure versions available - APG-M and -MP from atmosphere to 10 -3 mbar. APG-L from atmosphere to 10 -4 mbar. Iso2god latest version. Standard analogue output 0 to 10 V dc - Easy to interface with a computer or plc. Fault output indication. Adjustable set-point - For process control and interlocking. Provides vacuum status indication.
Edwards Active Pirani Gauge Manual Instructions
Set-point level read visually or with voltmeter. Low output impedance and integral Faraday shield - Provides high level of noise immunity. Permits long cable runs (up to 100 m). Corrosion resistant versions available. Two tube types (AI & StSt) & numerous flange types to suit customer applications.
